Product Description

Simple and network compatible scanner for business

SP-1125N scans documents at 25 ppm/50 ipm (A4 portrait 200/300 dpi) and loads up to 50 sheets at a time. With a compact and network compatible design, the unit provides high-value performance as an entry-level model for all businesses. A compact footprint allows the SP-1125N to be placed in locations with space restrictions. And even with its compact body, the scanner supports both USB 3.2 high-speed connection and wired network connection, so that it can be used not only near the computer but also in various places under the network environment.

Assistance for safe and reliable scanning

SP-1125N comes with brake rollers to deliver accurate page separation and prevent any multi-feeding errors from occurring. This mechanism and our ultrasonic multi-feed sensors combined, provide users with stable paper feeding, prevent any potential information loss from occurring, and enable scanning of all documents and cards at the office with maximised precision and efficiency. Application forms and ID cards at the reception desk, for instance, can be scanned in just one batch, allowing for quick processing and little customer wait time.

Flexible and easy operation to improve daily workflow

High-speed USB 3.2 and wired network connection expands the versatility of user operation so that users are no longer confined to operating near the computer. Operation is now possible in a wider variety of locations, with reliable network environment support. SP-1125N is also compact in size, making it the perfect scanner to use on a desk or reception space where space is limited. As an entry-level model, operation is simple with just 2 buttons to choose from: “Scan/Stop” and “Power ON/OFF”. This simple and easy-to-use design minimises scanning procedures and human errors in any organisation. All these features combined, enable anyone to operate the scanner anywhere.

Software for ultimate business efficiency

PaperStream IP for SP Series, the scanner driver supporting both TWAIN and ISIS, enables hassle-free scanning so that operators do not need to make fine OCR setting adjustments. The software automatically converts scanned images into exceptionally clean images, raising OCR accuracy, even when scanning wrinkled and soiled documents, or documents with background patterns. With PaperStream Capture, capture batches of all sizes with utmost efficiency.

Accurate feeding ability for various documents

The scanner handles a wide range of paper from thin to thick, as well as plastic cards to suit all scanning needs. Operators need not worry about unexpected interruptions, rescans, or damaged documents.

Document software for maximised flexibility

Connect business workflow with PaperStream IP and PaperStream Capture - "The PaperStream IP scanner driver, supporting both TWAIN/ISIS, eliminates the need of making fine setting adjustments for OCR processes. It automatically converts images into exceptionally clean images, accelerating OCR even when scanning wrinkled, soiled and patterned documents. With an intuitive interface, PaperStream Capture allows users to feed information into their organisation's workflow through various capture features during batch scanning effectively and efficiently."

Technical Specifications

• Supported operating systems : Windows® 11, Windows® 10, Windows Server® 2025, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, macOS 10.15 or later, Linux-Ubuntu 20.04 LTS or later.
• Scanner Type : ADF (Automatic Document Feeder)
• Scanning modes : Simplex / Duplex, Color / Grayscale / Monochrome
• Image Sensor Type : Single line CMOS-CIS x 2 (Front x 1, Back x 1)
• Light Source : R, G, B LED x 2 (Front x 1, Back x 1)
• Document size : Maximum: A4 Portrait (210 x 297 mm) or Legal (8.5 x 14 in.) or 8.5 x 34 in. (215.9 x 863.6 mm) (long page scanning: 3,048 mm (120 in.)); Minimum: A8 Portrait / Landscape (52 x 74 mm)
• Paper weight (Thickness) : Paper: 50 to 209 g/m2 (0.06 to 0.26 mm); A8 size: 127 to 209 g/m2 (0.15 to 0.26 mm); Plastic Card: ISO7810 ID-1 type compliant (0.76 mm or less, embossed plastic cards with total thickness of 1.24 mm or less)
• Scanning speed (A4, Portrait) : Simplex: 25 ppm (200 dpi / 300 dpi); Duplex: 50 ipm (200 dpi / 300 dpi)
• Paper chute capacity (A4, Portrait) : 50 sheets (A4: 80 g/m2) / 60 Sheets (A4: 64 g/m2)
• Expected daily volume : 3.000 sheets/day
• Background colors : White (Hardware, scanned background is gray)
• Optical Resolution : 600 dpi
• Output Resolution : 50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)
• Output format : Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
• Internal video processing : 65,536 levels (16-bit)
• Interface : USB 3.2 Gen1x1 Ethernet 10BASE-T,100BASE-TX,1000BASE-T
• Connector shape : B type
• Image processing function : Multi image output, Automatic color detection, Automatic page size detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Split image, De-Skew, Edge filler, Vertical streaks reduction, Digital endorser, Background pattern removal, Character thickness, Character augmentation, Character extraction
• Power requirement : AC 100 V to 240 V ± 10%
• Dimensions: Width x Depth x Height : 298 mm x 135 mm x 133 mm (11.7 in. x 5.3 in. x 5.2 in.)
• Weight : 2.5 kg
• Included software / drivers : PaperSteam IP for SP Series (TWAIN/TWAIN x64/ISIS), WIA Driver, Image Scanner Driver for macOS (ICA), Image Scanner Driver for Linux (SANE), PaperStream Capture, PaperStream ClickScan, Software Operationm Panel, Error Recovery Guide, ABBYY™ FineReader™ for ScanSnap, PaperStream Central Admin, ABBYY™ FineReader Sprint™, Network Setup Tool for SP Series, SP Series Online Update

What's in the Box

• SP-1125N
• AC adapter
• USB cable
• Setup DVD-ROM
